Technical Specifications
| Parameter | Specification |
|---|---|
| Measurement Method | Magnetic induction / Eddy current |
| Thickness Range | 0-5000 microns |
| Accuracy | plus or minus (1 micron + 1% of reading) |
| Probe Type | Integrated or external probe options |
| Data Storage | 1000+ readings with statistics |
| Applicable Standards | ISO 2178, ISO 1461, ASTM B499 |
Key Features
- Instant digital readout — no calibration needed on flat surfaces
- Suitable for both ferrous (magnetic) and non-ferrous substrates
- Statistics mode: mean, min, max, standard deviation per batch
- USB data export for QC documentation
- Compact and portable — use in production line or field inspection
Zinc Coating Quality and Insulator Service Life
The hot-dip galvanized coating on insulator metal fittings is the primary defense against atmospheric corrosion. IEC 60383 specifies minimum zinc coating thicknesses (typically 85-100 microns for standard applications, heavier for aggressive environments). Regular thickness testing is a routine QC requirement for insulator manufacturers.
