Technical Specifications
| Parameter | Specification |
|---|---|
| Temperature Range | -70 to +180 deg C |
| Temperature Change Rate | 5-15 deg C/min (model dependent) |
| Interior Volume | 225L / 500L / 1000L / Custom |
| Temperature Uniformity | plus or minus 2 deg C |
| Controller | Touchscreen PLC with profile programming |
| Applicable Standards | IEC 60068-2-14, IEC 61109, IEC 62217 |
Key Features
- Rapid temperature change capability for accelerated testing
- Touchscreen controller with 100+ profile memory
- Viewing window with heated glass to prevent fogging
- Cable port for in-chamber electrical measurements
- Over-temperature and compressor protection
Temperature Cycling in Insulator Standards
Temperature cycling tests are specified across multiple IEC insulator standards. They verify that the insulator materials and interfaces can withstand repeated thermal expansion and contraction without degradation. This is particularly important for composite insulators where polymer housing, FRP core rod, and metal fittings have different thermal expansion coefficients.
