Technical Specifications
| Parameter | Specification |
|---|---|
| Mixing Ratio | 1:1 to 10:1 (adjustable) |
| Output Rate | 0.5-20 L/min |
| Material Supply | 200L drum or 20L pail pump |
| Degassing | Vacuum chamber, < 5 mbar |
| Color Dosing | Integrated pigment metering pump |
| Control | PLC with recipe management |
Key Features
- Servo-driven positive displacement pumps for ratio accuracy
- Static or dynamic mixer options depending on material type
- Vacuum degassing eliminates air bubbles in molded housings
- Automatic drum changeover for continuous production
- Recipe storage for different silicone formulations and colors
Precise Material Preparation for Consistent Quality
Silicone rubber housing quality starts with accurate material preparation. Two-component LSR materials must be mixed at the exact specified ratio — deviation causes inconsistent curing, variable hardness, and reduced tracking resistance. The dosing system ensures every shot of material delivered to the injection molding machine has identical composition.
