Technical Specifications
| Parameter | Specification |
|---|---|
| Temperature Range | -40 to +180 deg C |
| Humidity Range | 10-98% RH |
| Humidity Accuracy | plus or minus 2.5% RH |
| Interior Volume | 225L / 500L / 1000L |
| Control | Touchscreen PLC, 100 programs |
| Applicable Standards | IEC 60068-2-78, IEC 62217 |
Key Features
- Precise temperature and humidity control with independent PID loops
- Direct water supply system for long-duration testing
- Anti-condensation heated viewing window
- Cable gland for in-chamber electrical testing
- Data logging via USB or Ethernet
Humidity Conditioning in Insulator Testing
Many IEC insulator tests require specimens to be conditioned at specified temperature and humidity levels before testing. For example, composite insulator tracking tests require specimens conditioned at 23 plus or minus 2 deg C and 50 plus or minus 5% RH for 24 hours. Consistent conditioning ensures reproducible test results.
