Technical Specifications
| Parameter | Specification |
|---|---|
| Production Speed | 0.1-1.5 m/min |
| Rod Diameter | 10-100 mm |
| Fiber Type | ECR or E-glass, up to 96 ends |
| Resin System | Epoxy, vinyl ester, polyester |
| Heating Zones | 3-zone PID controlled die heating |
| Cutting | Automatic flying cut-off saw |
Key Features
- Multi-creel fiber rack with tension control per roving
- Resin bath with temperature and viscosity control
- Heated forming die with multi-zone precise temperature control
- Pull mechanism with caterpillar or reciprocating grip
- Automatic cut-to-length with tolerance plus or minus 2mm
Pultrusion — The Heart of Composite Insulator Manufacturing
The pultrusion process continuously pulls glass fiber rovings through a resin bath, then through a heated die where the composite cures into a solid rod. The quality of the pultruded core rod — fiber wet-out, void content, and cure degree — fundamentally determines the composite insulator's mechanical and electrical performance.
