Technical Specifications
| Parameter | Specification |
|---|---|
| Measurement Method | Telecentric optical imaging + laser |
| Accuracy | plus or minus 0.02 mm |
| Parameters | Eccentricity, coaxiality, roundness, cylindricity, parallelism |
| Specimen Range | 50-500mm diameter, up to 4000mm length |
| Cycle Time | 60-120 seconds per unit |
| Output | 3D deviation map, GD&T report, SPC data |
Key Features
- Telecentric lens eliminates perspective error for precise measurement
- Single setup measures all geometric parameters
- 3D color deviation map for visual quality assessment
- Automatic report generation with pass/fail per tolerance table
- Integration with production MES for real-time quality trending
Comprehensive Geometric Inspection
Modern insulator production requires comprehensive geometric verification — not just individual dimension checks. Eccentricity between the core rod and housing, coaxiality of end fittings, and form tolerances of machined surfaces all affect assembly fit and mechanical performance. This automated optical station replaces multiple manual measurement tools with a single, fast measurement cycle.
