Technical Specifications
| Parameter | Specification |
|---|---|
| Max Capacity | 3000 kN (300 ton) |
| Platen Size | 400 x 400 mm |
| Platen Hardness | 60 HRC minimum |
| Loading Rate Control | Stress-controlled / strain-controlled |
| Applicable Standards | IEC 60305, ISO 7500-1, EN 12390-4 |
| Safety | Shatter guard + transparent safety door |
Key Features
- Self-aligning spherical upper platen for uniform load distribution
- Four-column rigid frame for maximum stiffness
- Digital load rate controller with auto-pacing per standard
- Fragmentation protection with polycarbonate shatter guard
- Suitable for concrete cubes, cylinders, and insulator specimens
Compression Testing in Insulator Quality Control
While tensile and bending tests dominate insulator mechanical testing, compression testing is essential for specific insulator types — particularly station post insulators that experience compressive loads from busbar weight and short-circuit forces. Compression tests also verify the quality of concrete poles and foundations used in substation construction.
