Technical Specifications
| Parameter | Specification |
|---|---|
| Tank Material | Stainless steel 304 |
| Heating Method | Electric immersion heaters |
| Temperature Control | PID with digital display |
| Specimen Capacity | Up to 12 insulator units per batch |
| Applicable Standards | IEC 60383, IEC 62217, ANSI C29.1 |
| Safety | Low water level cut-off, over-temperature protection |
Key Features
- Stainless steel construction for corrosion resistance with salt solutions
- Programmable boiling duration timer with automatic shut-off
- Perforated specimen basket for uniform water exposure
- Lid with condensation return to maintain water level
- Optional NaCl dosing system for salt water boiling per IEC 62217
The Boiling Test in Porcelain Insulator Standards
IEC 60383-1 specifies the boiling test as a sample test for porcelain insulators. The insulator is immersed in boiling water for a specified duration then immediately subjected to a thermal shock (immersion in cold water) or electrical test. This verifies that the porcelain body does not absorb water — a sign of insufficient vitrification or micro-cracks in the glaze.
