Technical Specifications
| Parameter | Specification |
|---|---|
| Max Bending Moment | 200 kNm |
| Loading Direction | Horizontal / Vertical |
| Moment Arm Adjustment | 100-2000 mm |
| Applicable Standards | IEC 60305, ANSI C29.2 |
Key Features
- Rigid steel frame with reinforced base for high bending loads
- Adjustable moment arm for different insulator heights
- Real-time load vs deflection graph with data logging
Understanding Cantilever Strength Requirements
Post insulators and long rod insulators experience significant bending moments from wind loads and conductor tension. The cantilever failing load test measures the maximum load the insulator can withstand when loaded at its free end.
